3 Axis Hot Bar Soldering Machine Allows X Y Movement During Soldering

Hot Bar Soldering Machine Description:

Hot bar soldering machine is a precision welding equipment based on pulse heating technology, which achieves precise temperature control welding through short-term and high-frequency pulse current or energy output, especially suitable for welding requirements of temperature sensitive or micro components. Pulse welding machines, with their precise and low damage characteristics, have become a key tool for high-end electronic manufacturing and miniaturized equipment production, especially in scenarios that require high reliability and minimal thermal impact, and cannot be replaced.

Hot Bar Soldering Machine Functions:

1. Independent control of X, Y, and Z axes.
   • Enables accurate alignment and positioning of soldering head and components.
   • Ideal for complex or multi-point soldering tasks.

2. Uses a thermally controlled heating element (thermode) to apply heat directly to the joint.
   • Suitable for flex-to-PCB, FFC/ FPC to PCB, and wire-to-pad connections.

3. Adjustable soldering temperature (typically 100°C–500°C).
   • Controlled downward pressure ensures proper bonding.
   • Real-time monitoring of temperature and force.

Hot Bar Soldering Machine Features:

1. Unique pulse heat technology provides fastest soldering head heating.

2. Programmable soldering temperature, heat-up rate and time duration for a wide range of products.

3. Thermocouple is fixed in close proximity to the working surface & the thermode, thus providing accurate temperature feedback control.

4. Closed Loop PID temperature control with clearly visible LED display.

5. Soldering time can be programmable and is triggered by temperature.

6. Floating thermode ensures consistent pressure and heat transfer between the thermode head and the parts to be joined.

7. Programmable pressure switch with LCD display for precise force control.

8. CCD camera system with magnification lens can be retrofitted for fine-pitch positioning.

Hot Bar Soldering Machine Specification:

Hot Bar Soldering Machine Application:

Usually, we can't use SMT + reflow furnace for welding devices. Originally, we can use constant temperature soldering iron for manual welding, but manual welding has some defects, such as inconsistent operation proficiency, uneven operation, even false welding or damaged products. The pulse hot press is different from the constant temperature soldering iron. The pulse hot press can reach the required temperature at the moment of power on. Once there is no voltage at both ends of the pressure head, the air cooling can quickly reach the room temperature, and the pressure head is flat, so the welded products have the same appearance, stable yield and simple operation.
